Fully Automatic Soap Making Machine | 100-3000kg/h Capacity | Stainless Steel 304
Fully Automatic Soap Making Machine | 100-3000kg/h Capacity | Stainless Steel 304
Product Details
Place of Origin: China
Brand Name: LOVO
Model Number: 5001-10000
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 5000-10000
Packaging Details: 1000X5000X1000 cm
Delivery Time: 10-25
Payment Terms: Western Union,T/T,D/P,D/A,L/C
Supply Ability: 666
Get Best Price
Product Details
Highlight:
automatic soap making line
,3000kg/h soap making line
,3000kg/h fully automatic soap making machine
Product Description
Fully Automatic Soap Making Machine with Stainless Steel 304 Components and 100-3000kg/h Capacity
Soap Making Machine Small Beauty Soap Production Line Chemical Soap Plodder Machine
We offer complete toilet and laundry bar soap production equipment lines with capacities ranging from 100kg/h to 2000kg/h. Our laundry soap production line includes mixing systems, three-roller mills, double-screw double-layer vacuum plodders, refrigeration units, vacuum strip cutting, and soap cutting machines.
- Mix all materials using mixing agitators, grind soap noodles with three-roller mills, form soap bars with vacuum plodders, and cut soaps with stamping machines
- Distribution boxes control all machine motors, while conveyors transport soap materials
- Water pumps cool the vacuum plodders, and vacuum pumps vacuumize soap materials
- Components contacting soap materials can be manufactured from stainless steel 304
Key Specifications
| Machine Type | Soap Machine | Automatic Grade | Fully Automatic |
|---|---|---|---|
| Voltage | 380V, 220V | Core Components | PLC, Motor, Gearbox, Pump |
| Warranty | 1 Year | Machinery Test Report | Provided |
| Brand Name | LOVO | Model Number | LV600 |
| Place of Origin | Henan, China | Weight | 1000 kg |
| Capacity | 100-3000 kg/h | Applicable Industries | Manufacturing Plant |
Technical Parameters
Soap Cutting Machine
- Soap bar dimensions: Length 70mm-600mm, Thickness ≤55mm, Width ≤90mm
- Cutting accuracy: ±1g
- Motor power: 1.2kw
- Overall dimensions: 820x500x1080mm
- Equipment weight: 110kg
Our electronic laundry soap cutting machine features continuous automatic cutting of soap bars from the plodder into cakes or stamping patterns. With electronic tracking system, it can cut laundry soap bars of different sizes and weights after computer setting. The mold wheels are driven by soap bar movement from the plodder, ensuring clear characters, vertical ends, smooth and neat surfaces, and easy operation.
Soap Production Line Process
Mixer
Equipped with motor and gearbox to fully stir soap flakes with various liquid and solid additives. Provides thorough and uniform stirring, completely dissolving color paste and additives into the soap base to meet different customer formula requirements.
Three-Roller Mill
Features three horizontally arranged rollers operating at varying speeds. Soap particles undergo squeezing and shearing on the roller surfaces to achieve optimal grinding effect.
Double Layer Vacuum Plodder Machine
Composed of two-stage discharge screw system. The primary stage functions as a single refiner machine to manufacture soap noodles under vacuum. At the final stage, soap noodles are compressed, squeezed, and continuously output as soap bars.
Electric Soap Cutting Machine
- Size: 800x300x1000mm
- Power: 6kw
- Frequency: 50HZ
- Voltage: 380V
- Function: Cutting and printing
Detailed Specifications
| Product Name | SOAP Cutting Machine |
|---|---|
| Capacity | 100-2000 kg/h |
| Speed of Mixing Drum | 20-40 r/min |
| Motor Power | 2.6-6 KW |
| Warranty | 1 Year |
